LCD |
Display type |
21.5" TFT-LCD |
|
Max. Resolution |
1920 x 1080 |
|
|
Max. Colors |
16.7M (6 bit) |
|
|
Luminance (cd/m2) |
250 |
|
|
Viewing angle (h/v) |
170° / 160° |
|
|
Led backlight lifetime (hrs) |
30,000 hrs |
|
|
Touch screen |
Type |
P-CAP |
|
Touch screen |
True-flat 10 points |
|
|
System |
Processor |
10th Gen Intel® i3 10100TE CPU @ 2304 MHz 4 cores, 8 logical processors |
|
Chipset |
Intel® H410 |
|
|
System memory |
4 Gb DDR4 2667MHz (Non-ECC) |
|
|
Ethernet |
Intel® I219-LM Giga LAN |
|
|
Wireless |
802.11 A/B/G/N/AC + BT4.2 |
|
|
I/o port |
1 x DisplayPort 1.2 / 4 x USB 3.2 Gen 1 / 1 x DC Jack / 1 x RJ-45 / 1 x HDMI 1.4 / 1 x Line-out / 1 x Mic-in |
|
|
Storage |
256 Gb SSD hard drive |
|
|
Stereo speaker |
2 x 2W |
|
|
Operating system |
Windows 10 64-bit |
|
|
Side I/O port |
USB 2.0 |
2 |
|
4-in-1 card reader |
1 |
|
|
Optical Disk Drive |
DVD super-multi double layer |
|
|
Webcam |
2.0 HD mega pixel, HD 720p 16:9 lens with array digital microphone |
|
|
System bottom |
Power In |
|
|
Power requirement |
Power input |
19V DC-in connectivity |
|
Power adapter |
DC19V / 9.5A / 180W adapter / AC / DC |
|
|
Mechanical |
Mounting |
Desktop Stand |
|
Dimensions (w x d x h) |
538 x 429 x 213 mm (w/ Stand) |
|
|
Weight |
8.3kg (18.26 lb) |
|
|
Environmental |
Operating temperature |
0~ 40°C (32 ~ 104°F) |
|
Storage temperature |
-20 ~ 60°C (-4 ~ 140°F) |
|
|
Storage humidity |
10% ~ 95% @60°C non-condensing |
|
|
Vibration resistance |
Operating Random vibration Test 5-500Hz, 0.3 Grms with HDD |
|
|
Shock resistance |
Operating 50 G peak (3 ms duration) |
|
|
EMC |
CE / FCC Class B |
